Bench 001 Steel

  • Material
  • Dimensions
  • Color
  • Dimensions
  • Type

Esta combinación no existe.

Términos y condiciones

Bench 001 Steel
Efficient and suitable for public spaces such as parks, sidewalks, corridors and others, this high-quality detailed bench has a steel seat and back and comes in different color options, making it customizable to match the aesthetics of the environment.
Resource Download


CAD Technical drawing:
PDF Technical file:
Sustainability data sheet:

Specs

General measures​

Color Dark gray o Green
Dimensions 94 cm o 60 cm o 180 cm
Type Without armrests o With armrests
Material AA38 Aluminum and Carbon Steel Surface
Dimensions 180 cm / 60 cm x 79 cm x 58
Bench 001 Steel

Materials.


Steel

The basic material used for the manufacture of most product components is grade 11373 (S235JR) or better grade steel. The tolerances comply with the ISO 2768-1 «m» standard, quality of imperfections according to the EN 25817 «C» standard.

Most of steel parts are processed as follows:

    CNC laser cutting

    CNC bending

    Galvanizing - different methods

    Degreasing by washing at 80oC–iron phosphating (anti-corrosion protection)

    Achromatic passivation (cleaning with distilled water)

    Drying at a temperature of 190oC for 10-20 minutes

    Electrostatic powder coating application​
metallic finishes

All our products go through a series of processes according to the type of material and use, in order to provide the highest possible quality and durability; The combination of these processes is a particular art achieved in years of experience, which only the right technology and raw material allow.



The finishing method is according to the model and part of the product:


hot dip galvanized

Metallization

Zinc Paint​

Continuous galvanized

Electro-galvanized

Polyester paint
